Rev / Rotated - TJCTF 2026

A writeup on the Rev / Rotated challenge from TJCTF 2026

Loading... 5 min read
Language: English
Author: @harshfeudal
#CTF#Rev#ELF#Bash#Base64#Gzip#Byte Rotation#TJCTF#2026

The Challenge

rotated

Description

this file isn't making any sense to me. can you discover what it means?

Hint 1: look at the title
Hint 2: consider each byte separately

The attachment only contains one file named chall. Running file chall does not identify it as an ELF, PNG, ZIP, or regular text file:

TEXT
chall: data

So the goal is to figure out how the file was transformed, recover the real content, and continue reversing it until we get the flag.

The Walkthrough

Both hints are important:

  • rotated: the data has likely been rotated or shifted somehow;
  • consider each byte separately: the transformation is applied independently to each byte.

My first thought was bit rotation, such as rotating each byte left or right. However, after looking at the first few bytes, the pattern looked more like addition/subtraction modulo 256.

A Linux executable normally starts with the ELF magic:

TEXT
7f 45 4c 46

The first four bytes of chall are:

TEXT
9c 62 69 63

If we subtract 0x1d from each byte, we get:

TEXT
9c - 1d = 7f
62 - 1d = 45
69 - 1d = 4c
63 - 1d = 46

That recovers the exact ELF magic:

TEXT
7f 45 4c 46

Therefore, the original file was encoded with:

TEXT
encoded_byte = (plain_byte + 0x1d) mod 256

To decode it, we simply reverse the operation:

TEXT
plain_byte = (encoded_byte - 0x1d) mod 256

A minimal decoder is enough:

Python
from pathlib import Path

raw = Path("chall").read_bytes()
decoded = bytes((b - 0x1d) & 0xff for b in raw)
Path("chall.dec").write_bytes(decoded)

After decoding:

Bash
file chall.dec

The result is:

TEXT
chall.dec: ELF 64-bit LSB shared object, x86-64, version 1 (SYSV), statically linked, no section header

The file is now a valid ELF binary.

Stage 2: the ELF drops a Bash script

After making the decoded ELF executable and running it:

Bash
chmod +x chall.dec
./chall.dec

It creates a new file named script.sh in the current directory.

The generated script.sh is heavily obfuscated with Bash parameter expansion. Instead of manually reading the very long obfuscated line, the fastest method is to run it with trace mode:

Bash
bash -x script.sh

The trace reveals the real commands:

Bash
++ printf H4sIAEDAzmkC/0tNzshXUPLJz8/OzEtXSMsvUkhUSMtJTLdXUlBWSHEvyEpxjzKPzAo0THSzzPY18jL0y7Es8XMJNfY19rJ0Tre1BQCGqZA9QQAAAA==
++ base64 -d
++ gunzip -c
+ eval 'echo "Looking for a flag?" # dGpjdGZ7YjQ1aF9kM2J1Nl9tNDU3M3J9Cg=='

So script.sh is basically doing:

Bash
printf '<gzip-base64-blob>' | base64 -d | gunzip -c

and then evaling the decompressed result.

After base64-decoding and gzip-decompressing the blob, we get:

Bash
echo "Looking for a flag?" # dGpjdGZ7YjQ1aF9kM2J1Nl9tNDU3M3J9Cg==

When executed normally, Bash only runs the part before the #, so we only see:

TEXT
Looking for a flag?

However, the real flag is hidden in the comment as another base64 string:

TEXT
dGpjdGZ7YjQ1aF9kM2J1Nl9tNDU3M3J9Cg==

Decoding it:

Bash
echo dGpjdGZ7YjQ1aF9kM2J1Nl9tNDU3M3J9Cg== | base64 -d

gives the flag:

TEXT
tjctf{b45h_d3bu6_m4573r}

Final Exploit

The following script automates the full solve:

  1. read chall;
  2. subtract 0x1d from every byte to recover the ELF;
  3. run the ELF inside a temporary directory to obtain script.sh;
  4. extract the gzip+base64 blob from the script;
  5. decompress the payload;
  6. decode the base64 string hidden in the comment and print the flag.
Python
#!/usr/bin/env python3
import base64
import gzip
import re
import subprocess
import tempfile
from pathlib import Path


def main():
    raw = Path("chall").read_bytes()

    # Hint: "rotated" + "consider each byte separately".
    # The first four encoded bytes are 9c 62 69 63.
    # Subtracting 0x1d gives 7f 45 4c 46, the ELF magic.
    decoded = bytes((b - 0x1d) & 0xff for b in raw)

    if decoded[:4] != b"\x7fELF":
        raise SystemExit("[-] Decoding failed: ELF magic not found")

    with tempfile.TemporaryDirectory() as td:
        td = Path(td)
        exe = td / "chall.dec"
        exe.write_bytes(decoded)
        exe.chmod(0o755)

        # The decoded ELF drops script.sh in the current directory.
        subprocess.run([str(exe)], cwd=td, check=True, timeout=3)

        script = (td / "script.sh").read_text(errors="replace")

    blob = re.search(r"H4sI[A-Za-z0-9+/=]+", script)
    if not blob:
        raise SystemExit("[-] gzip+base64 blob not found")

    payload = gzip.decompress(base64.b64decode(blob.group(0))).decode()
    print(payload)

    for candidate in re.findall(r"[A-Za-z0-9+/]{12,}={0,2}", payload):
        try:
            msg = base64.b64decode(candidate).decode()
        except Exception:
            continue

        if "tjctf{" in msg:
            print(msg.strip())
            return

    raise SystemExit("[-] Flag not found")


if __name__ == "__main__":
    main()

Run it:

Bash
python3 run.py

Output:

TEXT
echo "Looking for a flag?" # dGpjdGZ7YjQ1aF9kM2J1Nl9tNDU3M3J9Cg==
tjctf{b45h_d3bu6_m4573r}

Why This Works

The challenge has several small obfuscation layers, but each layer is easy to peel once we follow the hints in the right order.

The full flow is:

TEXT
chall
  ↓ subtract 0x1d from every byte
valid ELF binary
  ↓ execute decoded ELF
script.sh
  ↓ deobfuscate Bash pipeline
base64 decode + gzip decompress
  ↓ inspect decompressed command
base64 hidden in Bash comment
  ↓ base64 decode
flag

The most important observation is that the initial transformation is not a whole-file rotation, and not XOR. It is a Caesar-style shift over individual bytes:

TEXT
plain_byte = encoded_byte - 0x1d mod 256

After that, the remaining work is just unpacking layers:

  • the decoded ELF drops script.sh;
  • the Bash script hides printf | base64 -d | gunzip -c behind parameter-expansion noise;
  • the decompressed payload prints a decoy message;
  • the real flag is in a base64-encoded Bash comment.

Final Words

This is a light but fun reversing challenge because the title and hints point directly to the correct first step. If we only run file on the original attachment, it looks meaningless. But once we compare the first few bytes with a familiar magic header, the 0x1d offset becomes obvious.

What I liked about the challenge is that the flag is not directly inside the recovered ELF. After the byte rotation, there is still an ELF dropper, an obfuscated Bash script, a base64+gzip layer, and finally a base64 string hidden inside a comment.

TEXT
tjctf{b45h_d3bu6_m4573r}
